GD-200 Portable Device Power Platform
Power Accessory
The GD-200 portable device power platform, our most compact power platform packing down to only 1.03M with a mast height of 2.2M, making it ideal for ease of transport and deployment.
With battery or mains power options, 3 - 75 hours run time can be obtained. Simply swap out the single rechargeable battery and you are up and running straight away.
.png)
.png)
Power on the Go
.png)
Details
Plug and Play:
Suitable for Radar, Sign & Display, Surveying Instruments, Sensors, Environmental Instruments and Communication Devices etc.
Universal Mounting Platform:
Multiple mounting holes fit most devices and can be customised for use.
Ultra-Long Working Hours:
Typical working hours 3-75 hours per individual battery.
USB Output - Dual rainproof USB outputs for charging two devices at once, rain or shine.
Phone Stand - Continue working while charging, the hook here can serve as a phone stand.
Multiple Power Supply Interfaces Available:
Including IR Indoor Camera, IR Outdoor Camera, PTZ Camera. Equipped with multiple adapters. Compatible with most surveillance and electronic devices.
Specifications
PRODUCT
Height: 1.1~2.2m
Input: DC 24V（D24-100） DC 29.4V (MC-1/MC-2)
Output Voltage: 12V 3A
Output Current: 40W
Typical Working Hours: 3h-75h (D24-100 x 1)
Net Weight: 6.6KG (Fitting only)*
Output(USB): 5V 3A
Battery: D24-100 (up to 1)
Operating Temperature: -10℃~50℃
AC Power: X1-75-56BH Driver x 1 - 14000lm
PACKAGE
Model: D-200(1pcs), MC-1(1pcs), D24-100(1pcs)
Carton: 1110*260*310mm
Gross Weight: 11kg
PCS/Carton: x 1
Dimensions
Closed: H-1305mm x W-235mm x D-200mm
Open: H-2220mm x W-508mm x D-585mm
Additional Components
This product is a bare unit only and requires a combination of the following extra components. Does not include mounted device units.
Information Downloads - GD-200
